Qhob Reinforceing Mesh yog tsim los ntawm cov hlau rods nrog ib txoj kab uas hla ntawm 3 mus rau 40 mm. Cov rods hlau no yog vertically sib txuas los ntawm qhov chaw vuam. Qhob reinforcement mesh rau vaj tse, kev lag luam thiab kev tsim kho xws li cov pob zeb taug kev thiab kev lag luam thiab kev lag luam hauv tsev, kev tsim vaj huam sib luag precast thiab thaj chaw hauv pem teb slabs thiab cov hauv paus. Peb cov hlau mesh yog ribbed steel uas txhim kho cov ntawv cog lus nrog cov pob zeb, txo qis cov pob zeb tawg uas yuav tshwm sim vim kev ua vaj tse. Smooth steel mesh kuj tuaj yeem tsim raws li cov neeg siv khoom tshwj xeeb.
Qhob reinforcing mesh, tseem hu ua reinforcing steel los yog rebar mesh, yog ib daim phiaj zoo li cov qauv ua los ntawm steel tuav los yog nyob ntawm tej welded ua ke ntawm kev sib tshuam. Nws lub hom phiaj tseem ceeb yog txhawm rau ntxiv dag zog thiab ntxiv dag zog rau cov pob zeb, xws li slabs, phab ntsa, thiab cov hauv paus, los ntawm kev muab lub zog tensile ntxiv los tiv thaiv lub zog tensile uas pob zeb tsis muaj zog tiv thaiv.
Specification ntawm pob zeb reinforcing mesh:
Hom:Qhob mesh hnyav hom (inch ntawm rods saum toj no 12 mm) thiab lub teeb hom (inch ntawm rebar rods los ntawm 3 mm mus rau 10 mm).
Khoom siv:stainless hlau rebar rods, galvanized steel rods (nrog nws zoo heev tiv thaiv corrosion, galvanized reinforcing mesh tuaj yeem siv tau zoo hauv cov dej ntub dej).
Mesh puab:duab plaub los yog square.
Kev ncua deb ntawm cov pas nrig100, 200, 300, 400 thiab 500 mm.
Mesh daim ntawv dav:650mm - 3800 hli.
Mesh daim ntawv Length:850 hli, 6m, 9m, 12m.
Standard reinforcing meshqhov loj me yog 6. 0 m × 2.4 m. Thiab 4.80 m × 2.4 m, 3.6 m × 2 m, 2 m × 4 m kuj muaj.
Yog tias koj xav paub ntau ntxiv txog peb cov khoom lag luam, thov hu rau peb thiab tos ntsoov yuav koom tes nrog koj.
| Cov khoom | Longitudinal Hlau (mm) | Ntug Hlau (mm) | Hla hlau (mm) | Sheet Nyhav (kg) |
|---|---|---|---|---|
| wb 7676 | 7.60@100 | 7.60@100 | 7.60@100 | 105 |
| wb 9567 | 9.50@200 | 6.75@100 | 9.50@200 | 80 |
| SRM8560 | 8.55@200 | 6.00@100 | 8.55@200 | 65 |
| SRM7660 | 7.60@200 | 6.00@100 | 7.60@200 | 52 |
| SWB 6747 Stb | 6.75@200 | 4.75@100 | 6.75@200 | 40 |
| SRM6047 | 6.00@200 | 4.75@100 | 6.00@200 | 33 |
| SRM4740 | 4.75@200 | 4.00@100 | 4.75@200 | 21 |
| Cov khoom | Longitudinal Hlau (mm) | Hla Hlau (mm) | Sheet Nyhav (kg) |
|---|---|---|---|
| RWM 1210 | 11.90@100 | 7.6@200 | 157 |
| RWM 1110 | 10.65@100 | 7.6@200 | 131 |
| RWM 9510 | 9.50@100 | 7.6@200 | 109 |
| RRM8610 | 8.55@100 | 7.6@200 | 93 |
| RWM 7610 | 7.60@100 | 7.6@200 | 79 |
| RWM 6810 | 6.75@100 | 7.6@200 | 68 |
| Cov khoom | Ntev hlau (4.8 m) | Hla hlau (2.4 m) | Qhov hnyav | |||||
|---|---|---|---|---|---|---|---|---|
| Loj (mm) | Pitch (mm) | Thaj tsam (mm2/m) | Loj (mm) | Pitch (mm) | Thaj tsam (mm2/m) | (kg / m2) | (kg / ntawv) | |
| qw 4810 | 10 | 200 | 393 | 10 | 200 | 393 | 6.16 | 70.96 |
| wb 4808 | 8 | 200 | 252 | 8 | 200 | 252 | 3.95 | 45.50 |
| qw 4807 | 7 | 200 | 193 | 7 | 200 | 193 | 3.02 | 34.79 |
| qw 4806 | 6 | 200 | 142 | 6 | 200 | 142 | 2.22 | 25.57 |
| qw 4805 | 5 | 200 | 98 | 5 | 200 | 98 | 1.54 | 17.74 |
| TSI 4812 | 12 | 100 | 1131 | 8 | 200 | 252 | 10.90 | 125.57 |
| TSI 4810 | 10 | 100 | 785 | 8 | 200 | 252 | 8.14 | 93.77 |
| TSI 4808 | 8 | 100 | 503 | 8 | 200 | 252 | 5.93 | 68.31 |
| TSI 4807 | 7 | 100 | 385 | 7 | 200 | 193 | 4.53 | 52.19 |
| TSI 4806 | 6 | 100 | 283 | 7 | 200 | 193 | 3.73 | 42.97 |
| TSI 4805 | 5 | 100 | 196 | 7 | 200 | 193 | 3.05 | 35.14 |
| TSI 4810 | 10 | 100 | 785 | 6 | 400 | 70.8 | 6.72 | 77.41 |
| TSI 4809 | 9 | 100 | 636 | 6 | 400 | 70.8 | 5.55 | 63.94 |
| TSI 4808 | 8 | 100 | 503 | 6 | 400 | 49.0 | 4.51 | 51.96 |
| TSI 4807 | 7 | 100 | 385 | 6 | 400 | 49.0 | 3.58 | 41.24 |
| TSI 4806 | 6 | 100 | 283 | 6 | 400 | 49.0 | 2.78 | 32.03 |
Cov khoom tso saib
Ntim
Kev ntim cov pob zeb ua kom muaj zog mesh feem ntau suav nrog kev ntim cov mesh yob lossis cov ntawv txheeb kom ruaj ntseg kom yooj yim rau kev thauj mus los, khaws cia, thiab tuav ntawm qhov chaw tsim kho.
Tau txais Daim Ntawv Qhia Ceev
1.Dab tsi yog cov txiaj ntsig ntawm kev siv cov pob zeb reinforcing mesh?
Kev txhawb nqa mesh pab txhim kho cov txheej txheem kev ncaj ncees ntawm cov pob zeb ua ke los ntawm kev txhim kho lawv cov kev tiv thaiv kom tawg, shrinkage, thiab kev ua haujlwm tsis zoo. Nws kuj tseem faib cov khoom sib npaug ntau dua, ua kom muaj zog, thiab txuas ntxiv lub neej ntawm cov pob zeb ua vaj tse.
2. Qhov twg yog pob zeb reinforcing mesh siv?
Kev txhawb nqa mesh feem ntau yog siv rau ntau yam kev tsim kho, suav nrog cov hauv paus, slabs, phab ntsa, kab, thiab lwm yam khoom siv. Nws yog ib qho tseem ceeb tshwj xeeb tshaj yog nyob rau hauv cov cheeb tsam uas cov pob zeb ua rau muaj zog tensile siab los yog qhov uas yuav tsum tau muaj kev txhawb zog ntxiv kom tau raws li cov kev qhia tshwj xeeb ntawm engineering.
3. Hom kev txhawb nqa mesh muaj dab tsi?
Kev txhawb nqa mesh tuaj nyob rau hauv cov duab sib txawv, qhov ntau thiab tsawg, ntsuas, thiab teeb tsa kom haum rau ntau yam kev tsim kho. Cov hom muaj xws li square mesh, rectangular mesh, thiab qee zaum hexagonal mesh. Qhov kev xaiv ntawm hom mesh nyob ntawm yam xws li daim ntawv thov, kev xav tau ntawm kev thauj khoom, thiab kev tsim qauv engineering.
4. Yuav ua li cas yog pob zeb reinforcing mesh ntsia?
Kev txhawb nqa mesh feem ntau yog nteg nyob rau hauv cov pob zeb thaum lub sij hawm pouring, positioned ntawm qhov tsim nyog qhov tob raws li ib tug engineering specifications. Kev txhim kho kom zoo suav nrog kev ua kom cov mesh tau txais kev txhawb nqa txaus, ruaj khov, thiab muab tso rau kom muaj kev sib koom ua ke thoob plaws hauv cov qauv pob zeb.
5. Puas tuaj yeem txhawb nqa mesh xeb?
Thaum lub sij hawm reinforcing mesh feem ntau yog ua los ntawm cov hlau muaj zog, nws tseem tuaj yeem ua rau lub sijhawm ntev yog tias raug cov dej noo thiab ib puag ncig. Txhawm rau tiv thaiv xeb thiab xeb, nws yog ib qho tseem ceeb uas yuav tsum tau siv galvanized lossis epoxy-coated mesh los yog siv cov txheej tiv thaiv tsim nyog ua ntej kev teeb tsa.
