Raws li tus kws tshaj lij5005 Aluminium Sheet Manufacturers thiab lwm tus neeg - Tuam Tshoj Hoobkas - SIBOASI, peb muab siab -zooAl-Mg alloy aluminium phajtsim rauarchitectural, kho kom zoo nkauj, thiab industrial sivthoob ntiaj teb. Peb5005 aluminium ntawvraug tsim raws liASTM B209, EN 485, thiab ISO 209 tus qauv, muaj nyob rau hauvH14, H16, H18, thiab H32 tempers, nrog thickness xws li los ntawm0.2mm txog 6.0mm, thiab customizablewidths, txiav- rau- ntev nplooj ntawv, thiab xim-coated ua. Nrogzoo heev corrosion kuj, nruab nrab lub zog, thiab zoo formability, 5005 txhuas ntawv yog zoo tagnrho rauarchitectural panels, vov tsev ntawv, phab ntsa cladding, hniav panels, thiab pre-painted aluminium daim ntaub ntawv, ua atxhim khu kev qha xaiv rau cov neeg cog lus, distributors, thiab façade manufacturers thoob ntiaj teb.
01
Siab Zoo
02
Khoom siv Advanced
03
Pab neeg tshaj lij
04
Kev Pabcuam Kev Cai
Khoom Description
5005 aluminium ntawvyog ibAl-Mg alloypaub rauzoo heev corrosion kuj, lub zog nruab nrab, thiab zooformability. Nws yog dav siv nyob rau hauvarchitectural panels, ru tsev nplooj ntawv, phab ntsa cladding, thiab hniav siv aluminiumqhov twgtsis kam mus rau sab nraum zoov ib puag ncig, av noo, thiab corrosionyog qhov tseem ceeb.
Nws compatibility nrogpainting, hmoov txheej, thiab anodizingua rau nws yog qhov kev xaiv nrov raukev tsim kho, kev lag luam, thiab kev kho kom zoo nkauj thoob ntiaj teb.
Tshuaj muaj pes tsawg leeg
| Element | Si | Fe | Cu | Mn | Mg | Zn | Al |
|---|---|---|---|---|---|---|---|
| Cov ntsiab lus | Tsawg dua los yog sib npaug li 0.3 | Tsawg dua lossis sib npaug li 0.7 | Tsawg dua los yog sib npaug li 0.1 | Tsawg dua los yog sib npaug li 0.2 | 0.8–1.2 | Tsawg dua los yog sib npaug li 0.2 | Tshuav |
Mechanical Properties
| Kub | Tensile zog (MPa) | Yield zog (MPa) | Elongation (%) |
|---|---|---|---|
| H14 | 145–185 | Ntau dua lossis sib npaug li 95 | Ntau tshaj los yog sib npaug 6 |
| H16 | 150–190 | Ntau dua lossis sib npaug rau 105 | Ntau dua lossis sib npaug li 5 |
| H18 | 160–200 | Ntau dua lossis sib npaug rau 115 | Ntau tshaj los yog sib npaug 4 |
| H32 | 170–210 | Ntau dua lossis sib npaug li 125 | Ntau dua lossis sib npaug 3 |
Khoom Specifications
| Yam khoom | Metric | Imperial | Sau ntawv |
|---|---|---|---|
| Alloy | 5005 | 5005 | Al-Mg Alloy |
| Kub | H14 / H16 / H18 / H32 | - | Cov kev xaiv muaj zog & kev ua haujlwm |
| Thickness | 0.2-6.0 hli | 0.008–0.236 hli | Kev cai thickness muaj |
| Dav | 500-2000 hli | 19.7-78.7 hli | Txiav - mus rau - dav lossis coil slitting kev pab cuam |
| Ntev | 1000-6000 hli | 39.4–236.2 hli | Kev cai txiav - mus rau - ntev muaj |
| Nto tiav | Mill tiav / Txhuam / Xim -Coated | - | Haum rau txheej los yog anodizing |
| Flatness kam rau ua | EN / ASTM cov qauv | ASTM cov qauv | Xyuas kom du nto rau txheej |
| Kev Ua Raws Cai | ASTM B209 / EN 485 / ISO 209 Cov Ntawv Pov Thawj | - | Cov qauv kev lag luam thoob ntiaj teb |
| Kev xaiv ua | Slitting, Txiav - mus rau -Length, Xim Txheej, Embossing | - | OEM / qhov project customization |
| Ntim | Export- tus qauv: Ntoo pallets lossis crates + Moisture - ntawv pov thawj + PE zaj duab xis | - | Coil qhov muag-rau-phab ntsa / qhov muag-rau- kev xaiv ntuj |
Ntsiab nta & qhov zoo
Zoo heev corrosion kuj- zoo tagnrho rau kev siv sab nraum zoov thiab ntug hiav txwv
Lub zog nruab nrab- haum rau architectural thiab zoo nkauj panels
Zoo formability- Txhawb kev khoov, yob txoj kev, thiab profileing
Kev kho deg tau tshaj- Zoo tagnrho rau kev pleev xim, hmoov txheej, thiab anodizing
Kev ntseeg tau zoo- cov khoom siv kho tshuab zoo ib yam rau cov haujlwm loj -
Tej kev siv
Architectural panels thiab phab ntsa cladding
Roofing nplooj thiab canopies
Kho kom zoo nkauj aluminium panels
Ua ntej-painted aluminium ntawv thiab coils
Sab nrauv facades thiab signage
Kev Tshawb Fawb & Kev Ua Haujlwm Zoo
Raw material chemical tsom xam (spectrometer)
Mechanical Properties Test (tensile, elongation)
Thickness & flatness soj ntsuam
Kev tshuaj xyuas qhov zoo ntawm qhov chaw (scratches, roj stains)
Thib peb-kev tshuaj ntsuam xyuas muaj (SGS, BV, TUV)
Ntim & Xa Cov Qauv
Export- txheem ntim nrognoo noo- ntawv pov thawj + PE zaj duab xis
Stacked rauntoo pallets los yog crates
Coil qhov muag-rau- phab ntsa lossis qhov muag-rau- ntuj xaiv muaj
Clear labeling ntawm alloy, temper, loj, thiab batch tooj
Daim Ntawv Qhia Txog Kev Txiav Txim Ceev - 5005 Aluminium Sheet
| Feature | Kev pom zoo |
|---|---|
| Cov Khoom Siv Zoo Tshaj Plaws | Architectural panels, vov tsev ntawv, phab ntsa cladding, hniav panels, pre-painted aluminium ntawv |
| Kub | H14 / H16 / H18 / H32 |
| Thickness Ntau | 0.2-6.0 hli |
| Lub zog | Nruab Nrab – haum rau cov uas tsis yog - cov ntawv thov |
| Formability | Zoo - txhawb kev khoov, dov, thiab profileing |
| Corrosion Resistance | Zoo heev - haum rau sab nraum zoov thiab ntug hiav txwv ib puag ncig |
| Nto xaiv | Mill tiav / Txhuam / Xim -Coated |
| Cov neeg yuav khoom | Cov neeg cog lus, distributors, facade manufacturers, hniav vaj huam sib luag tsim |
| Tswv yim buyer | Xaiv 5005 thaumcorrosion kuj thiab txheej adhesionyog qhov tseem ceeb tshaj qhov muaj zog ntawm cov qauv |
Tiv tauj peb
Nrhiav ibtxhim khu kev qha 5005 txhuas ntawv tsum / chaw tsim tshuaj paus / exporter? Tiv tauj peb hnub no
Peb qhov chaw nyob
Room 4107, Runfeng Building, Sanqiao Tshiab Street, Weiyang District, Xi'an City, Shaanxi Province
Xov tooj
+86 15769214734
E -mail
FAQ
Q1: Dab tsi yog 5005 txhuas ntawv siv rau?
A: 5005 txhuas ntawv yog dav siv hauvarchitectural panels, vov tsev ntawv, phab ntsa cladding, hniav panels, thiab pre-painted txhuas ntawv, tshwj xeeb hauvsab nraum zoov, ntug hiav txwv dej, thiab chaw ntub dejvim nwszoo heev corrosion kuj.
Q2: Dab tsi tempers muaj rau 5005 txhuas ntawv?
A: Kev npau taws muaj xws liH14, H16, H18, thiab H32, muab sib txawv ua ke ntawmformability thiab nruab nrab lub zogkom haum architectural los yog industrial daim ntaub ntawv.
Q3: Puas yog 5005 txhuas ntawv tuaj yeem pleev xim lossis coated?
A: Yog, 5005 yog qhov zoo rauhmoov txheej, pleev xim, thiab anodizing, ua rau nws nyiam alloy rauua ntej- pleev xim rau aluminium panels thiab coils.
Q4: Puas yog 5005 txhuas ntawv tuaj yeem welded?
A: Yog, 5005 tuaj yeem welded sivtxheem aluminium vuam txoj kev. Rau kev siv sab nraum zoov,ncej-weld corrosion tiv thaivtej zaum yuav xav tau.
Q5: Dab tsi thickness thiab qhov ntau thiab tsawg yog muaj?
A: Thickness ranges los ntawm0.2mm txog 6.0mm, dav ntawm500mm txog 2000mm, thiab ntev los ntawm1000mm txog 6000mm. Kev cai txiav - mus rau -ntev thiab coil slitting kev pab cuammuaj.
Q6: Yuav ua li cas 5005 piv rau 3003, 3004, 3005, thiab 3105?
A: 5005 muabzoo dua corrosion kujtshaj 3003 thiab 3004, nruab nrab lub zog, thiab yog nyiam rauarchitectural thiab hniav siv sab nraum zoov. 3105 zoo dua rauvov tsev ntawv, gutters, thiab pre-painted panels, thaum 3005 yog dav siv raucladding thiab sab nrauv architectural panels.
Q7: Dab tsi cov qauv 5005 txhuas ntawv ua tau raws li?
A: Peb 5005 txhuas ntawv ua raws liASTM B209, EN 485, thiab ISO 209. Thib peb-kev soj ntsuam tog (SGS, BV, TUV) tuaj yeem npaj tau raws li qhov kev thov.
Q8: Qhov kev txiav txim yam tsawg kawg nkaus (MOQ) yog dab tsi?
A: MOQ sib txawv raws lithickness, temper, thiab customization. Feem ntau, peb muab1-5 metric tons rau ib qho kev txiav txim, thiab OEM lossis ntau xaj tau txais tos.
Q9: Yuav ua li cas yog 5005 txhuas ntawv ntim rau export?
A: Export- txheem ntim suav nrognoo noo- ntawv pov thawj + PE zaj duab xis, stacked rauntoo pallets los yog crates. Coil ntim kev xaiv suav nrogqhov muag-rau- phab ntsa lossis qhov muag- mus rau - ntuj.
Q10: Kuv puas tuaj yeem xaj qhov ntau thiab tsawg lossis OEM ua?
A: Yog, peb muabkev cai dav, txiav- rau- ntev nplooj ntawv, slitting, xim txheej, embossing, thiab lwm yam kev pab OEMraws li tus neeg yuav khoom xav tau.
Q11: Cov lus qhia ntawm tus neeg yuav khoom - Yuav ua li cas xaiv qhov zoo aluminium alloy?
A: Kev taw qhia ceev:
3003-H14- Tus nqi -zoo, zoo heev formability, dav siv & rwb thaiv tsev
3004-H14/H18/H19- Lub zog siab dua rau cov thawv ntim khoom, cov kaus poom, cov vov tsev
3005-H14/H24- Architectural panels, vov tsev, sab nrauv cladding
3105-H24- ru tsev, gutters, rwb thaiv tsev, ua ntej- pleev xim rau cov ntawv txhuas
5005-H14/H16/H18/H32- Sab nraum zoov vaj huam sib luag, cladding, hniav panels, ua ntej- pleev xim rau txhuas nrog zoo heev corrosion kuj
